Lathe

LT 250/550

Item number: #36001012

Description

The LT 250/550 has a Ø26mm spindle bore, a high precision main spindle with a high-quality FUERDA center chuck + LED worklights.

It offers thread cutting, variable speed (50-2000 rpm), and operates on 1x230v power.

Additionally, it is mounted on a base with 2 d...
Read More >>

×

Product Specifications

Swing over bed 250mm
Swing over cross slide 150mm
Tail diameter Ø30mm
Tail height 125mm
Distance between centers 550mm
Width of bed 135mm
Spindlebore (mm) 26
Taper of spindlenose MK-4
Number of spindle speeds Variable
Range of spindle speed 50-2000rpm
Metric threads 0.2-4.0mm
Imperial threads 8~56 T.P.I.
Range of longitudinal leed 0.07~0.40mm
Type of toolholder 4-way
Max. travel of compound slide 70mm
Max. travel of cross slide 115mm
Max. travel of main slide 450mm
Spindle travel 80mm
Taper in Tailstock Spindle MK-2
Voltage 1x230V
Main motor 1100 watt
Length (mm) 1200
Width (mm) 560mm
Height (mm) 580mm
Weight 130kg
