Lathe

LT 360/1000

Item number: #36001022

Description

The LT 360/1000 features a Ø52mm spindle bore and operates within a versatile speed range of 70-2000 rpm across 8 steps. Equipped with a 3-axis LCD monitor GDXH i200 featuring digital readout, it ensures precision and efficiency in your operations. Its heavy cast iron base provides stability, while the quick change tool post facilitates seamless...
Read More >>

×

Product Specifications

Swing over bed 360mm
Swing over gap 502mm
Swing over cross slide 160mm
Tail diameter Ø42mm
Tail height 180mm
Spindlenose Camlock D1-5
Distance between centers 1000mm
Width of bed 187
Spindlebore (mm) 52mm
Taper of spindlenose MK-6
Number of spindle speeds 8
Range of spindle speed 70-2000rpm
Metric threads 0.4-7.0mm
Imperial threads 4~56 T.P.I.
Range of longitudinal leed 0.05~1.39mm
Type of toolholder Multi
Max. travel of compound slide 95mm
Max. travel of cross slide 160mm
Max. travel of main slide 1000mm
Spindle travel 100mm
Taper in Tailstock Spindle MK-3
Voltage 3x400V
Main motor 1,5kW
Length (mm) 1930
Width (mm) 760
Height (mm) 1600
Weight 510kg
